Name: Estimated OWMS density

Display Field: category

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Estimated OWMS in Canterbury were mapped in 2025 using a method described in the Journal of Hydrology New Zealand by PHF Science. The layer shows one-hectare grid cells where one or more consented or estimated OWMS are located within the cell. Full details are given in the PHF Science report "Estimating onsite wastewater densities and their associated Total Nitrogen and Total Phosphorus mass loading rates across Waitaha Canterbury" by Qui and Humphries, February 2026.

Copyright Text: PHF Science and Environment Canterbury

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000.0

Max Scale: 1500.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1329218.0269
YMin: 5015464.9276
XMax: 1687818.0269
YMax: 5354964.9276
Spatial Reference: 2193  (2193)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: category
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1
  Label: 1
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [254, 240, 217, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: 2-4
  Label: 2 - 4
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [253, 204, 138, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: 5-10
  Label: 5 - 10
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [252, 141, 89, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: >10
  Label: >10
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [215, 48, 31, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Join_Count ( type: esriFieldTypeInteger, alias: Join Count )
• TARGET_FID ( type: esriFieldTypeInteger, alias: Target FID )
• category ( type: esriFieldTypeString, alias: Category, length: 512 )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape_Area )
• grid_id ( type: esriFieldTypeInteger, alias: Grid ID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
