Name: Estimated OWMS nitrogen load discharged in drinking water protection zones

Display Field: SUPPLY_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: PHF Science estimated the Total Nitrogen loading from OWMS discharges in each CDWPZ using mapped OWMS locations (for consented and estimated OWMS) and applying assumptions from measured nitrogen concentrations in wastewater. Further details are documented in the PHF Science Report "report "Estimating onsite wastewater densities and their associated Total Nitrogen and Total Phosphorus mass loading rates across Waitaha Canterbury" by Qui and Humphries, February 2026.

Copyright Text: PHF Science

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 2000000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1344412.6233
YMin: 5020155.7158
XMax: 1674625.9071000004
YMax: 5333504.1521
Spatial Reference: 2193  (2193)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Class Breaks Renderer:
Field: SUM_TN_loading_per_year_kg
Min. Value: 6.079999923706055
ClassBreakInfos:
• Class Maximum Value: 50
  Label: 5 - 50 kgN/yr
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [247, 244, 249, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 100
  Label: 50 - 100 kgN/yr
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [212, 185, 218, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 250
  Label: 100 - 250 kgN/yr
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [223, 101, 176, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 500
  Label: 250 - 500 kgN/yr
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [206, 18, 86, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Class Maximum Value: 647.0639953613281
  Label: 500 - 650 kg N/yr
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [103, 0, 31, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• WELL_NO ( type: esriFieldTypeString, alias: Well No., length: 9 )
• WELL_TYPE ( type: esriFieldTypeString, alias: Well Type, length: 50 )
• SUPPLY_NAME ( type: esriFieldTypeString, alias: Supply Name, length: 254 )
• MOH_SOURCE_NUMBER ( type: esriFieldTypeString, alias: Ministry of Health Source Number, length: 16 )
• MOH_SUPPLY_NUMBER ( type: esriFieldTypeString, alias: Ministry of Health Supply Number, length: 16 )
• COMMUNITY_SUPPLY_TYPE ( type: esriFieldTypeString, alias: Community Supply Type, length: 255 )
• COMMUNITY_SUPPLY_CLASSIFICATION ( type: esriFieldTypeString, alias: Community Supply Classification, length: 255 )
• DEPTH ( type: esriFieldTypeDouble, alias: Depth )
• TOP_SCREEN ( type: esriFieldTypeDouble, alias: Top Screen )
• AREA_HA ( type: esriFieldTypeDouble, alias: Area (ha) )
• VERIFIED_DATE ( type: esriFieldTypeDate, alias: Verified Date, length: 8 )
• SUM_TN_loading_per_year_kg ( type: esriFieldTypeDouble, alias: SUM TN loading (kg/year) )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
